Name: Sewer Components

Display Field: RECORD_DRAWING_NAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This point feature class is used by LACPW's Sewer Maintenance Division to represent various sewer system components including valves, fittings, cleanouts, and low-pressure system components. With the adoption of the first low-pressure system in LA County's Sewer Network, a need arose for a point feature class other than the Sewer Manhole feature class.Principal attributes include:SEWER_COMPONENT_TYPE – this field is used to document the broader component typeValve – a valve is used to provide a form of system isolation, allowing maintenance crews to conduct maintenance activitiesFitting – a pipe component such as a bend, wye, or tee that may serve as a junction for several sewer pipesCleanout – a terminal structure along a pipe run that allows access for cleaning at one endSEWER_COMPONENT_SUBTYPE: this field is used to document a more specific component type, such as a combination air release / vacuum valveLOCATION: a textual description of the component’s locationJUR: the City or Community where the feature existsRECORD_DRAWING_NAME: the name of the record drawing that shows the componentMAINTAINED_BY: field to document the party responsible for the component’s maintenanceCOMPONENT_MATERIAL: a field to list the component material type

Copyright Text: This data is maintained by the Los Angeles County Public Works – Sewer Maintenance Division. Sandra Medina, (626) 300-3363. samedina@dpw.lacounty.gov

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 30000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6300514.80762214
YMin: 1720001.94836894
XMax: 6641180.70470071
YMax: 2091942.75206469
Spatial Reference: 102645  (2229)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: SEWER_COMPONENT_TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: FITTING
  Label: FITTING
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [168, 112, 0, 255]
  Size: 5.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
• Value: VALVE
  Label: VALVE
  Description: N/A
  Symbol:
  Style: esriSMSCircle
  Color: [156, 156, 156, 255]
  Size: 5.0
  Angle: 0.0
  XOffset: 0
  YOffset: 0
  Outline:
  [0, 0, 0, 255] Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerPointLabelPlacementAboveRight
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 8
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 3000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: COMPONENT_SUBTYPE

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• LOCATION ( type: esriFieldTypeString, alias: LOCATION, length: 255 )
• JURISDICTION ( type: esriFieldTypeString, alias: JURISDICTION, length: 50 )
• RECORD_DRAWING_NAME ( type: esriFieldTypeString, alias: RECORD DRAWING NAME, length: 50 )
• DOCUMENT_CENTER_ID ( type: esriFieldTypeString, alias: DOCUMENT CENTER ID, length: 50 )
• STATUS ( type: esriFieldTypeString, alias: STATUS, length: 50 , Coded Values: [UNKNOWN: UNKNOWN] , [ABANDONED: ABANDONED] , [IN CONSTRUCTION: IN CONSTRUCTION] , ...3 more... )
• MAINTAINED_BY ( type: esriFieldTypeString, alias: MAINTAINED BY, length: 50 )
• DATE_CONSTRUCTED ( type: esriFieldTypeDate, alias: DATE CONSTRUCTED, length: 8 )
• COMPONENT_MATERIAL ( type: esriFieldTypeString, alias: COMPONENT MATERIAL, length: 50 )
• MAPPING_NOTES ( type: esriFieldTypeString, alias: MAPPING NOTES, length: 512 )
• DECOMISSIONED_DATE ( type: esriFieldTypeDate, alias: DECOMISSIONED_DATE, length: 8 )
• MAPSHEET_NUMBER ( type: esriFieldTypeSmallInteger, alias: MAPSHEET NUMBER )
• FIELD_NOTES ( type: esriFieldTypeString, alias: FIELD NOTES, length: 512 )
• FIELD_INSPECTION_DATE ( type: esriFieldTypeDate, alias: FIELD INSPECTION DATE, length: 8 )
• CREATED_USER ( type: esriFieldTypeString, alias: CREATED_USER, length: 255 )
• CREATED_DATE ( type: esriFieldTypeDate, alias: CREATED_DATE, length: 8 )
• LAST_EDITED_USER ( type: esriFieldTypeString, alias: LAST_EDITED_USER, length: 255 )
• LAST_EDITED_DATE ( type: esriFieldTypeDate, alias: LAST_EDITED_DATE, length: 8 )
• GLOBALID ( type: esriFieldTypeGlobalID, alias: GLOBALID, length: 38 )
• CW_ASSETID ( type: esriFieldTypeString, alias: CITYWORKS ASSETID, length: 50 )
• MMS ( type: esriFieldTypeString, alias: MMS, length: 16 )
• MANHOLE_NUMBER ( type: esriFieldTypeSmallInteger, alias: MANHOLE_NUMBER )
• CONDUIT_SERVED ( type: esriFieldTypeString, alias: CONDUIT_SERVED, length: 50 , Coded Values: [GRAVITY: GRAVITY] , [LOW PRESSURE: LOW PRESSURE] , [FORCE MAIN: FORCE MAIN] )
• COMPONENT_SUBTYPE ( type: esriFieldTypeSmallInteger, alias: COMPONENT_SUBTYPE )
• COMPONENT_TYPE ( type: esriFieldTypeString, alias: COMPONENT_TYPE, length: 50 )
• RIM_TO_INVERT ( type: esriFieldTypeDouble, alias: RIM_TO_INVERT_(FT) )
• RIM_TO_GROUND_SURFACE ( type: esriFieldTypeDouble, alias: RIM_TO_GROUND_SURFACE_(FT) )
• LID_ELEVATION ( type: esriFieldTypeDouble, alias: LID_ELEVATION_(FT) )
• VERTICAL_DATUM ( type: esriFieldTypeString, alias: VERTICAL_DATUM, length: 50 , Coded Values: [NAVD88: NAVD88] , [NGVD29: NGVD29] )
• LID_DIAMETER ( type: esriFieldTypeSmallInteger, alias: LID_DIAMETER_(IN) )
• SUPERVISORIAL_DISTRICT ( type: esriFieldTypeString, alias: SUPERVISORIAL_DISTRICT, length: 1 )
• CITY_OR_COMMUNITY ( type: esriFieldTypeString, alias: CITY_OR_COMMUNITY, length: 75 )
• MACP_MANHOLE_INDEX_OM ( type: esriFieldTypeDouble, alias: MACP_MANHOLE_INDEX_O&M )
• MACP_MANHOLE_INDEX_STR ( type: esriFieldTypeDouble, alias: MACP_MANHOLE_INDEX_STRUCTURAL )
• MACP_INSPECTION_DATE ( type: esriFieldTypeDate, alias: MACP_INSPECTION_DATE, length: 8 )

Types:

ID: 1
Name: MANHOLE
Domains:
• CONDUIT_SERVED:
  Inherited
• COMPONENT_TYPE:
  Coded Values: [FORCE MAIN AIR INJECTION: FORCE MAIN AIR INJECTION] , [FORCE MAIN DISCHARGE: FORCE MAIN DISCHARGE] , [DOUBLE TRAP: DOUBLE TRAP] , ...15 more...
• STATUS:
  Inherited
• VERTICAL_DATUM:
  Inherited
• LID_DIAMETER:
  Coded Values: [24: 24 INCH] , [26: 26 INCH] , [27: 27 INCH] , ...2 more...

---

ID: 2
Name: CLEANOUT
Domains:
• CONDUIT_SERVED:
  Inherited
• COMPONENT_TYPE:
  Coded Values: [LAMP HOLE: LAMP HOLE] , [CLEANOUT: CLEANOUT] , [TERMINAL: TERMINAL]
• STATUS:
  Inherited
• VERTICAL_DATUM:
  Inherited

---

ID: 3
Name: VALVE
Domains:
• CONDUIT_SERVED:
  Inherited
• COMPONENT_TYPE:
  Coded Values: [LPSS AIRVAC: LPSS AIRVAC] , [LPSS ISOLATION: LPSS ISOLATION] , [GATE: GATE] , ...4 more...
• STATUS:
  Inherited
• VERTICAL_DATUM:
  Inherited

---

ID: 4
Name: OTHER STRUCTURE
Domains:
• CONDUIT_SERVED:
  Inherited
• COMPONENT_TYPE:
  Coded Values: [LPSS FLUSHING CONNECTION: LPSS FLUSHING CONNECTION] , [AIR SCRUBBER: AIR SCRUBBER] , [PUMP STATION - OTHER AGENCY: PUMP STATION - OTHER AGENCY] , ...3 more...
• STATUS:
  Inherited
• VERTICAL_DATUM:
  Inherited

---
